Door Hardware>Door Closer > DC001
Material : | Surface Mount Door Closer |
Main Body Size : | 207mm L. x 55mm W. x 40mm H. |
Power Size : | EN2, EN3, EN4 |
Accessories : | Available with standard arm, hold open arm, or slide arm |
Finishes : | Painted – Silver / Black / White / Brown Satin anodized aluminum. Polished anodized aluminum. |
Selectable closing force
Power Size | EN2 | EN3 | EN4 | EN5 | EN6 |
Max. Door Width (mm) | 850 | 950 | 1100 | 1250 | 1400 |
Max. Door Weight (Kgs) | 40 | 60 | 80 | 100 | 120 |
Max. Opening Angle | 180° | 180° | 180° | 180° | 180° |
Features & Application :
* All DAC001 Series closer are currently in the process of full compliance testing in accordance with EN1154.
* Universal application. Non-Handed for standard, top jamb, parallel arm installation.
* Adjustable closing & latching speeds.
Note :
* Doors of unusual height or weight, or doors subject to severe wind or draft conditions require the next larger model closer than the usual.
* Do not use hold open closers on fire doors.
.jpg)
.jpg)
Door Hardware>Door Closer > DC002
Material : | Surface Mount Door Closer |
Main Body Size : | 246mm L. x 62mm W. x 44mm H. |
Power Size : | EN2, EN3, EN4, EN5, EN6 |
Accessories : | Available with standard arm, hold open arm, or slide arm |
Finishes : | Painted – Silver / Black / White / Brown Satin anodized aluminum. Polished anodized aluminum. |
Selectable closing force
Power Size | EN2 | EN3 | EN4 | EN5 | EN6 |
Max. Door Width (mm) | 850 | 950 | 1100 | 1250 | 1400 |
Max. Door Weight (Kgs) | 40 | 60 | 80 | 100 | 120 |
Max. Opening Angle | 180° | 180° | 180° | 180° | 180° |
Features & Application :
* All DC002 Series closer are currently in the process of full compliance testing in accordance with EN1154.
* Universal application. Non-Handed for standard, top jamb, parallel arm installation.
* Adjustable closing & latching speeds.
Note :
* Doors of unusual height or weight, or doors subject to severe wind or draft conditions require the next larger model closer than the usual.
* Do not use hold open closers on fire doors.
.jpg)
Door Hardware>Door Closer > DC003
Material : | Concealed Door Closer |
Main Body Size : | 230mm L. x 56mm W. x 30mm H. |
Power Size : | EN3, EN4, EN5 |
Accessories : | Available with wide concealed arm & thin concealed arm |
Finishes : | Painted – Silver / Black / White / Brown Satin anodized aluminum. Polished anodized aluminum. |
Selectable closing force
Power Size | EN2 | EN3 | EN4 | EN5 | EN6 |
Max. Door Width (mm) | 850 | 950 | 1100 | 1250 | 1400 |
Max. Door Weight (Kgs) | 40 | 60 | 80 | 100 | 120 |
Max. Opening Angle | 180° | 180° | 180° | 180° | 180° |
Features & Application :
* All DC003 Series closer are currently in the process of full compliance testing in accordance with EN1154.
* Adjustable closing & latching speeds.
* Universal application. Non-Handed
Note :
* Do not use hold open closers on fire doors.
* Doors of unusual height or weight, or doors subject to severe wind or draft conditions require the next larger model closer than the usual.
* All concealed door closers to be installed on the door at least 36mm/metal and 40mm/wooden with standard installation, 33mm/metal and 37mm/wooden with overhead installation.
.jpg)
.jpg)
Door Hardware>Door Closer > DC004
Material : | Zinc Die Cast Economical Mount Door Closer (Hydraulic) |
Main Body Size : | 3-1/2” H. x 2-3/4” W. x 2” D |
Finishes : | Painted – Silver / Black / White |
Features & Application :
* For use on interior solid-core wood and metal door
(maximum : 45kgs /up to 3’ W. x 7’ H.)
* Easy to installation
Door Hardware>Door Closer > DSC001
Product Name : | Pneumatic Touch – Hold Door Closer |
Size : | 1-1/4” O.D. x 9” or 10” L. |
Function : | Light Duty |
Finishes : | Painted – Silver / Black / White |
Features & Application :
* For wood or metal storm and screen Door.
* For doors up to o 1-1/4” thickness.
* For outswinging door to open full 90°
* Auto release.
Door Hardware>Door Closer > DSC002
Material : | Standard Hydraulic Door Closer |
Size : | 1” O.D. x 10-1/2” L. |
Function : | Heavy Duty |
Finishes : | Painted – Silver / Black / White |
Features & Application :
* For wood or metal storm and screen Door.
* For doors up to o 1-1/4” thickness.
* For outswinging door to open full 90°
Door Hardware>Door Closer > DSC003
Material : | Pneumatic Screen Door Closer |
Size : | 1-1/4” O.D. x 9” L. |
Function : | Light Duty |
Finishes : | Painted – Silver / Black / White |
Features & Application :
* For wood or metal storm and screen Door.
* For doors up to o 1-1/4” thickness.
* For outswinging door to open full 90°
Door Hardware>Door Closer > DSC004
Material : | Pneumatic Screen Door Closer |
Size : | 1-1/4” O.D. x 9” L. |
Function : | Light Duty |
Finishes : | Painted – Silver / Black / White |
Features & Application :
* For wood or metal storm and screen Door.
* For doors up to o 1-1/4” thickness.
* For outswinging door to open full 90°
Door Hardware>Door Closer > DSC005
Material : | Pneumatic Screen Door Closer |
Size : | 1-1/4” O.D. x 9” L. |
Function : | Light Duty |
Finishes : | Painted – Silver / Black / White |
Features & Application :
* For wood or metal storm and screen Door.
* For doors up to o 1-1/4” thickness.
* For outswinging door to open full 90°
Door Hardware>Door Closer > DSC006
Material : | Pneumatic Screen Door Closer |
Size : | 1-1/4” O.D. x 10-1/2” L. |
Function : | Light Duty |
Finishes : | Painted – Silver / Black / White |
Features & Application :
* For wood or metal storm and screen Door.
* For doors up to o 1-1/4” thickness.
* For outswinging door to open full 90°
Door Hardware>Door Closer > DSC007
Material : | Pneumatic Screen Door Closer |
Size : | 1-1/4” O.D. x 9” L. |
Function : | Light Duty |
Finishes : | Painted – Silver / Black / White |
Features & Application :
* For wood or metal storm and screen Door.
* For doors up to o 1-1/4” thickness.
* For outswinging door to open full 90°
Door Hardware>Door Closer > DSC008
Material : | Shock – Absorber Screen Door Closer |
Size : | 1-1/4” O.D. x 9” L. |
Function : | Light Duty |
Finishes : | Painted – Silver / Black / White |
Features & Application :
* For wood or metal storm and screen Door.
* For doors up to o 1-1/4” thickness.
* For outswinging door to open full 90°
* External extra spring for shock-absorber opening
* “Fast Latch” Features
Door Hardware>Door Closer > DSC009
Material : | Pneumatic Screen Door Closer |
Size : | 1-1/2” O.D. x 10-5/8” L. |
Function : | Light Duty |
Finishes : | Painted – Silver / Black / White |
Features & Application :
* For wood or metal storm and screen Door.
* For doors up to o 1-1/4” thickness.
* For outswinging door to open full 90°
Door Hardware>Door Closer > WHD001
Features & Applications :
l Zinc Die Cast Door Push Pull Latch.
l For all out swinging door 3/4” to 1-1/4” Thick.
l Mounting hole spacing 1-3/4” Ctr.
l Available in various finish
l Screen and storm door hardware.
l Contains two size of strikes and shims to provide adjustment for latching.
Door Hardware>Door Closer > WHD002
Features & Applications :
l Zinc Die Cast Door Push Pull Latch.
l For all out swinging door 3/4” to 1-1/4” Thick.
l Mounting hole spacing 1-3/4” Ctr.
l Available in various finish
l Screen and storm door hardware.
l Installation hardware included
Door Hardware>Door Closer > WHD003
Features & Applications :
l Zinc Die Cast Door Keyed Push Pull Latch.
l For all out swinging door 3/4” to 1-1/4” Thick.
l Mounting hole spacing 1-3/4” Ctr.
l Available in various finish
l Screen and storm door hardware.
l Installation hardware included.
Door Hardware>Door Closer > WHD004
Features & Applications :
l Zinc Die Cast Door Push Pull Latch.
l For all out swinging door 3/4” to 1-1/4” Thick.
l Mounting hole spacing 1-3/4” Ctr.
l Resilient Strike.
l Available in various finish
l Screen and storm door hardware.
l Installation hardware included
Door Hardware>Door Closer > WHD005
Features & Applications :
l Zinc Die Cast Door Keyed Push Pull Latch.
l For all out swinging door 3/4” to 1-1/4” Thick.
l Mounting hole spacing 1-3/4” Ctr.
l Available in various finish
l Screen and storm door hardware.
l Installation hardware included.
Door Hardware>Door Closer > WHD006
Features & Applications :
l Zinc Die Cast Door Key Knob Latch.
l For all out swinging door 3/4” to 1-1/8” Thick.
l Mounting hole spacing 1-3/4” Ctr.
l Resilient strike.
l Available in various finish.
l Screen and storm door hardware.
l Installation hardware included
